Butyl Sealing Machine

Butyl Sealing Machine
Available Models:
JYJ-05
1.This machine is used coating butyl glue for bended spacer
2. Automatic adjust width of glue nozzle for different spacers
Tel: +86 185 6372 1087
Tel: +86 185 6372 1087
Contact Email: info@jingyouglassmachine.com

Product Introduction

Available Models:

JYJ-05

1.This machine is used coating butyl glue for bended spacer
2. Automatic adjust width of glue nozzle for different spacers


Key Features

1.Specially designed for coating butyl on IG aluminum spacers.

2.PLC control system with touch screen interface, simple operation.

3.Servo motor drive with intelligent speed adjustment.

4.Hydraulic system uses imported components for uniform output.

5.Functions include no-glue alarm, one-button glue change, and exhaust.

6.Quick-change system saves glue replacement time.


Technical Specifications

Parameter

JYJ-05 - Detailed Specifications

Power supply

380V / 50Hz

Total power

4.5 kW

Glue coating temperature

110 ~ 140 ℃

Extruding pressure

10 ~ 18 MPa

Transfer speed

0 ~ 60 m/min

Rubber cylinder diameter

200 mm

Width range of gluing head

6 ~ 35 mm

Overall dimension

2750 × 750 × 930 mm
